Oscilloscope Poster

Oscilloscope - An oscilloscope, previously called an oscillograph , and informally known as a scope, CRO (for cathode-ray oscilloscope), or DSO (for the more modern digital storage oscilloscope), is a type of electronic test instrument that allows observation of constantly varying signal voltages, usually as a two-dimensional graph of one or more electrical potential differences using the vertical or y‑axis, plotted as a function of time (horizontal or x‑axis). Many signals, for example sound, can be converted to voltages and displayed this way. Signals are often periodic and repeat constantly, so that multiple samples of a signal which is actually varying with time are displayed as a steady picture. Many oscilloscopes (storage oscilloscopes) can also capture non-repeating waveforms for a specified time, and show a steady display of the captured segment.
